CHB series intelligent temperature controller

CHB series is an economical controller developed by Winpark. It uses single chip microcomputer as control center and possesses functions like digital PID, auto tune, refined circuit design, mature control program and imported components. All these make it a controller with stable and reliable function, wide adaptability and strong anti-interference ability. It is widely used in conventional temperature control occasion, it is cost-effective and customers rate it highly all the time.

尺寸:
Quantity:

—Panel Size: 48mm×48mm×85mm;48mm×96mm×82mm;96mm×48mm×82mm;           72mm×72mm×82mm;96mm×96mm×82mm;160mm×80mm×70mm

—Control Mode: PID control, ON/OFF control

—Input Mode: thermocouple input, RTD input

—Output Mode: break output

—Refrigeration Mode: no refrigeration, ON/OFF refrigeration, proportional refrigeration

—Alarm Mode: no alarm, deviation upper limit alarm, deviation lower limit alarm

—Input Type: K;E;Pt100;Cu50;J

—Output Type: no refrigeration output; relay output; logical level output; single SCR zero cross output

—Refrigeration Type: no alarm output; relay output; logical level output; single SCR zero cross output

—Alarm Type: relay output; logical level output; single SCR zero cross output

—Temperature Range: 0℃~100℃;0℃~150℃;0℃~400℃;0℃~600℃;0℃~800℃;0℃~999℃

—Power supply: Null:180—240V; -EP:85—260V


—Rated Voltage: 180~240V AC 50/60Hz;85~260V AC 50/60Hz

—Power Consumption: ≤5W

—Accuracy: 0.5%FS

—Resolution: 1℃

—Ambient Temperature: 0℃~50℃

—Relative Humidity: 35%~85%(no condensation)

—Wiring Method: terminals
